LED Shadowless Ceiling Mounted Operating Light Examination Lamp

Overview Product Description Features of LED Operating Lamp: 1.OSRAM LED bulbs2.50000 hours bulb life3.titanium main arm;

Send inquiry

Basic Info

Model NO.	LOL77
Input Power(Va	350
Rated Voltage of Bulb	24V
Power Supply(AC)	220V±10% 50Hz
Depth of Light Beam (mm)	≥500
Rated Power of Bulb	300W
Application Field	Surgical
Transport Package	Standard Export Packing
Trademark	LongMed
Origin	China
Production Capacity	1000

Product Description

LED Shadowless Ceiling Mounted Operating Light Examination Lamp

Features of LED Operating Lamp:

1.OSRAM LED bulbs2.50000 hours bulb life3.titanium main arm4.ONDAL spring arm5.Endo model illiumination :10000lux6.R9 function:≥97Technical Specification:Diameter of lighthead:72cmIllumination at 1m:80000~160000 LUXLight field diameter at 1m:10-28 cmOptional color temperature:(3500-4500)±500KAverage bulb life:50000 hoursHeat to light ratio:<6Number of LED bulbs:45working distance:70-140 cmPower supply:100-240V,50/60HZInput Power: 90VA

LOL77
Illumination at 1m(lux)	160000/160000
Illumination at 1m on Endo mode(lux)	15000
Light field diameter at 1m (cm)	10-28
Light field diameter D10(mm)	180±40/180±40
D50(mm)	110±35/110±35
L1+L2 Depth of illumination(cm)	150
Color rendering index(Ra)	100≥Ra≥85
Optional color temperature(K)	6700≥Tc≥3000
Number of LED bulbs	45/45
Average bulb life (hours)	50,000
Heat-to-light ratio(mW/m ²lx)	<6
Working distance(cm)	70-140
Power supply	100-240 V, 50/60HZ
Max. power consumption(VA)	150W/150W
Ceiling height for installation(cm)	270-320
