Byond Medical High Precision Micro Intravenious Automatic Syringe/Infusion Pumps with Touch Screen for Best Manufacturer Price in China
Basic Info
Model NO. | Anim-8 |
Communication with His | Yes |
Work Modes | 9 Workmodes: Simple Mode, Drop Mode,Vol/T Mode,Vo |
Compatible Dock Station | Sunfusion Fs3 |
IV Set | Univeral Standard Infusion Sets |
Infusion Rate Range | 0.1 to 2000 Ml/H, with 0.01ml/H Increasement |
Volume to Be Infused (Vtbi) | 0.1-9999.99ml (0.01ml/Step) |
Infusion Time | 99h:59m:59s |
Purge/Bolus | Kvo, Bolus, Purge,Anti-Bolus |
Pressure Detection System | Dps, 13 Levels of Pressure Detection |
CPU | Dual Microprocessor Controlled |
Medicine Library | Drug Library,1000 Drug Provided |
History | 2000 History Recorded |
Dimention /Net Weight | 300*180*90mm, 2.0kg |
Transport Package | Standard Carton Package or as Customer′s Requireme |
Specification | 300*180*90mm |
Trademark | BYOND |
Origin | China |
HS Code | 9018909911 |
Production Capacity | 50000000pieces/Year |
Product Description
Features:
1.New Design.PBT plastic material·Stacked track and shackle design,pumps can becombined freely,greatly save space and easy to transfer.2.Intuitive and Informative User Interface.3.5"colour touch screen,Simple UI design, the important parameters easy be set.3.Various and Intelligent Mode.Fast start,eliminate the deviation caused by start delay ,Compatible for universal IV sets,Various work mode .4.User-friendly Design.Change infusion rate without pause,Intelligent Visual and audible alarm system and dynamic alarm guidance,Flow compensation to avoid error caused by pipeline fatigue,Equipment maintenance cycle alert, Regularly alert maintenance to make accuracy and safety of the device
Specification:
Model | Semi-2 | Erch-6 | Anim-8 |
Screen | 3.5 inch Blue LCD,touch screen | 3.5 inch Blue LCD ,touch screen | 3.5'' Color LCD ,touch screen |
WiFi module | NO | YES | NO |
Communicate with Host | NO | YES, Can be monitored by central work station system ID3 | YES, Can be monitored and controled by Infusion management system FS3 |
communication with HIS | NO | NO | YES |
Work modes | 7 Workmodes: Simple mode, Drop mode,Vol/T mode,Vol/W mode,Micro mode,Sequential mode,Intermittent mode | 7 Workmodes: Simple mode, Drop mode,Vol/T mode,Vol/W mode,Micro mode,Sequential mode,Intermittent mode | 9 workmodes: Simple mode, Drop mode,Vol/T mode,Vol/W mode,Micro mode,Sequential mode,Intermittent mode, Ramp Up/Down mode and |
Compatible dock station | Sunfusion PI3 | Sunfusion PI3 + ID3 | Sunfusion FS3 |
UI | Multiple lanuage (English,chinese,can be can be customized) | ||
Quick start , rapid installation | |||
Auto-lock knob | |||
Night mode | |||
IV set | Univeral standard infusion sets | ||
INFUSION rate range | 0.1 to 2000 mL/h, with 0.01ml/h increasement | ||
Nominal flow rate accuracy | ± 3% , while flow rate ≥ 1ml/h ± 5%,while flow rate ≤ 1ml//h | ||
Volume to be infused (VTBI) | 0.1-9999.99ml (0.01ml/step) | ||
Purge/Bolus | KVO, Bolus, Purge,Anti-bolus | ||
Medicine Library | Drug library,1000 drug provided | ||
History | 2000 history recorded | ||
Power | AC: 100-240V 50/60HZ; DC: 15V,1A; Battery: More than 7 hours backup time at rate of 25ml/h | ||
Dimention /net weight | 300*180*90mm, 2.0kg |
